Lifting Plan Template (Singapore Standard - WSH Guidelines) sample



Lifting Plan Template (Singapore Standard - WSH Guidelines)

This template follows the Workplace Safety and Health (WSH) Guidelines on Safe Lifting Operations in Singapore. It ensures compliance with local regulations, including the WSH Act, SS 536:2008 (Code of Practice for Safe Use of Mobile Cranes), and MOM Lifting Requirements.

---

LIFTING PLAN

(As per Singapore Standard and WSH Guidelines)

1. General Information

• Project Name: [Insert Project Name]
• Location of Lift: [Site Address]
• Date & Time: [DD/MM/YYYY] | [Time]
• Lift Type: ☐ Ordinary Lift ☐ Critical Lift
• Prepared By: [Name & Designation]
• Reviewed By: [Name & Designation]
• Approved By: [Competent Person]

2. Load Details

• Description of Load: [E.g., Steel Beams, Machinery, Pipes]
• Weight of Load: [XX] kg / tonnes
• Dimensions (L × W × H): [XX] m × [XX] m × [XX] m
• Center of Gravity: [Position]
• Any Special Considerations: [E.g., Fragile, Off-center weight]

3. Lifting Equipment & Accessories

• Type of Crane Used: ☐ Mobile Crane ☐ Tower Crane ☐ Crawler Crane ☐ Other: ________
• Crane Make & Model: [E.g., Tadano ATF 220G-5]
• Crane Capacity: [XX] tonnes
• Boom Length & Radius: [XX] m / [XX] m
• Lifting Accessories:
  • Sling Type: [Wire Rope / Chain / Synthetic]
  • Sling Length & SWL: [XX] m / [XX] tonnes
  • Shackles & SWL: [XX] tonnes
  • Hooks, Spreader Bars, Other: [Specify]
• Equipment Inspection Date: [DD/MM/YYYY] (Ensure valid Lifting Gear Certification)

4. Lifting Methodology

• Step-by-Step Procedure:
  1. Site Preparation – Set up exclusion zone, inspect ground conditions
  2. Crane Setup – Position crane, check boom angle, secure outriggers
  3. Load Securing – Attach slings/shackles, balance load
  4. Lifting Process – Signal confirmation, slow and controlled lift
  5. Load Placement – Lower load safely, confirm stability before release
  6. Post-Lift Checks – Inspect equipment, return to safe position

5. Personnel Involved

6. Risk Assessment & Control Measures

7. Site Preparation & Environmental Considerations

• Weather Check: ☐ Clear ☐ Rain ☐ Windy ☐ Other: _______
• Ground Stability Check: ☐ Stable ☐ Requires reinforcement
• Exclusion Zone Set: ☐ Yes ☐ No
• Barricades & Signage: ☐ Installed ☐ Not Required
• Permit to Work (PTW) Required: ☐ Yes ☐ No

8. Communication Plan

• Method: ☐ Hand Signals ☐ Radio ☐ Verbal Commands
• Responsible Person for Coordination: [Name]

9. Approval & Signatures

---

This Lifting Plan complies with Singapore’s WSH Act, SS 559:2010 (Code of Practice for Safe Lifting), and MOM Guidelines on Safe Lifting Operations.
